High performance power divider: precise signal allocation, empowering diverse scenarios

As the core component of RF systems, power dividers are widely used in communication, satellite navigation, radar, and testing and measurement fields. We focus on developing high-precision and low loss power divider solutions to help customers achieve stable and efficient signal distribution and synthesis.

Core advantages of the product

1. Ultra low insertion loss

1) Using high-purity dielectric substrate and precision microstrip line design, the typical insertion loss is as low as 0.3dB @ 2GHz, minimizing signal attenuation to the greatest extent possible.

2) Supports broadband coverage (DC-18GHz) to meet high-frequency requirements such as 5G base stations and satellite communication.

2. Excellent amplitude/phase consistency

1) Full frequency range amplitude balance ± 0.5dB, phase consistency ± 3 °, ensuring multi-channel signal synchronization, suitable for MIMO systems and phased array antennas.

3. High isolation design

1) The isolation between ports is ≥ 20dB (typical value), effectively suppressing channel crosstalk and improving the system signal-to-noise ratio.

4. Diversified configurations

1) Provide 2/3/4/6/8 equally divided and non equally divided models, supporting customized impedance (50 Ω/75 Ω), connector type (SMA/N/TNC), and packaging form (cavity/PCB).

5. Adaptability to harsh environments

1) Working temperature range -55 ° C~+85 ° C, IP67 protection level (chamber type), suitable for harsh environments such as vehicle mounted, ship mounted, and outdoor base stations.

Comparison Table of Key Parameters

Typical application scenarios

1. 5G communication system: Base station antenna array signal allocation, supporting Massive MIMO technology.

2. Satellite navigation terminal: Multi band signal synthesis to enhance GNSS reception sensitivity.

3. Testing laboratory: Collaborate with vector network analyzer to achieve multi port automated calibration.

4. Defense and Aerospace: Radar Signal Splitting, Multi Channel Synchronization of Electronic Warfare Systems.

Why choose us? ‌

✅ Full process quality control: 100% port standing wave ratio testing+high and low temperature cycling aging verification.

✅ Fast delivery capability: Standard models can be shipped within 3 days and support small batch samples.

✅ Complete certification: compliant with ISO 9001, RoHS, MIL-STD-202G standards.

✅ Technical support: Provide free S-parameter files, 3D models, and system integration suggestions.

Get samples or customized solutions immediately

Welcome to request technical information or apply for free test samples through the following methods:
